Canon imageFORCE C7165 is our highest-performing model, built to drive your business forward with exceptional output, advanced features and unmatched reliability. Delivering top-tier colour output with innovative D2 exposure technology, the C7165 ensures sharp, vibrant prints for every need.
| Machine Type | A3 Colour Multifunctional |
| Core Functions | Print, Copy, Scan, Send, Store and Optional Fax |
| Processor Speed | 1.8 GHz Dual Core Processor |
| Control Panel | 10.1″ TFT LCD WSVGA Colour Touch panel |
| Memory | RAM: 6 GB |
| Storage | Standard: (SSD) 256 GB Optional: (SSD) 1 TB |
| Interface Connection | NETWORK Standard: 1000Base-T/100Base-TX/10Base-T Optional: Wireless LAN (IEEE 802.11a/b/g/n/ac/ax)OTHERS Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1 Optional: Serial Interface, Copy Control Interface |
| Paper Input (Standard) | 1,200 sheets |
| Paper Supply Capacity (A4, 80 gsm) |
Standard: 1,200 sheets 100-sheet Multi-purpose tray x 1 550-sheet Paper cassette x 2 Maximum: 6,350 sheets (with High Capacity Cassette Feeding Unit-F1 + Paper Deck Unit-F2) |
| Paper Output Capacity (A4, 80 gsm) |
Maximum: 3,450 Sheets (with Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2 and 3rd Copy Tray Kit-A1) |
| Finishing Capabilities | Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, V-fold, C-fold, Z-fold
Note: Finishing capabilities vary depending on the options connected. |
| Supported Media Types | Multi-purpose Tray: Thin, Plain, Recycled, Eco, Colour, Heavy, Coated, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope, Water Resistant |
| Supported Media Sizes | Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5RCustom size: 98.0 x 139.7 mm to 320.0 x 457.2 mm Free size: Long sheet*1: Envelopes: Envelope custom size: 98.0 x 90.0 mm to 320.0 x 457.2 mm |
| Supported Media Weights | Multi-purpose tray: 52 to 300 gsm Paper Cassette (Upper): 52 to 256 gsm Paper Cassette (Lower): 52 to 300 gsmDuplex: 52 to 256 gsm |
| Warm-up Time | Quick Startup Mode: 4 Seconds or less*2 |
| Dimensions (W x D x H) |
723 x 722 x 937 mm |
| Installation Space (W x D) |
Basic: 1,137 x 1,162 mm (Right Cover Open with Multi-purpose tray extended + Cassette Drawers Open)
Fully Configured: 2,221 x 1,162 mm (Staple Finisher-AB3/Paper Folding/Booklet Finisher-A2 with the extension tray extended + Paper Folding Unit-L1 + Paper Deck Unit-F2 + Cassette Drawers open) |
| Weight | Approx. 115 kg |
Print Specifications
| Print Speed | Up to 70 ppm*3 (A4, A5*4, A5R, A6R*4) Up to 33 ppm (A3) Up to 42 ppm (A4R) |
| Print Resolution (dpi) | 4,800 x 2,400 dpi |
| Page Description Languages | Standard: UFR II, PCL6/PCL5, Adobe® PostScript® 3™ |
| Double-Sided Printing | Yes |
| Direct Print | Supported file types: PDF, EPS, TIFF/JPEG, and XPS |
| Mobile / Cloud Printing | AirPrint, Mopria, IPP Everywhere, Canon PRINT, uniFLOW Online, Universal Print and Cloud Connector.
A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information. |
| Fonts | PS fonts: 136 Roman PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*5 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*6 |
| Print Features | Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced Hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer |
| Operating System | UFRII: Windows® 10/11/Server2016/Server2019/Server2022, macOS (10.14 or later)
PCL: Windows® 10/11/Server2016/Server2019/Server2022 PS: Windows® 10/11/Server2016/Server2019/Server2022, macOS (10.14 or later) PPD: Windows® 10/11/Server2016/Server2019/Server2022, macOS (10.14 or later) |
Copy Specifications
| Copy Speed | Up to 70 ppm*3 (A4, A5*4, A5R, A6R*4) Up to 33 ppm (A3) Up to 42 ppm (A4R) |
| First-Copy-Out Time | Approx. 2.7/3.7 seconds or less (A4, BW/CL) |
| Copy Resolution (dpi) | 600 x 600 (dpi) |
| Multiple Copies | Up to 999 copies |
| Magnification | Variable zoom: 25% to 400% (1% Increments) |
| Copy Features | Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Colour Mode, Reserved Copy, Copy Sample |
Scan Specifications
| Type | Single-pass Duplexing Automatic Document Feeder*7 [2-sided to 2-sided (Automatic)] |
| Pull Scan Specifications | Colour Network ScanGear2 for both TWAIN and WIA |
| Scan Resolution (dpi) | 600 x 600 (dpi) |
| Acceptable Originals/Weights | Document Feeder media weight: 38 to 220 gsm (BW, CL)
Note: An acceptable weight of A6R or smaller is 50 to 220 gsm. |
| Scan Method | Push Scan, Pull Scan, Scan to Box, Scan to Advanced Space, Scan to Network, Scan to USB Memory Key, Scan to Mobile devices, Scan to cloud (uniFLOW Online*8/Cloud Connector*8) |
| Scan Speed | 1-sided Scanning: 135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)2-sided Scanning: 270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy) |
| Double-Sided Scanning | Yes |
Send Specifications
| Optional / Standard | Standard |
| Destination | Standard: E-mail/Internet FAX (SMTP*9), SMB, FTP, WebDAV, Mail Box Optional: Super G3 FAX, IP Fax |
| Address Book / Speed Dials | LDAP (2,000)/Local (1,600)/Speed dial (200) |
| Send Resolution (dpi) | 1-sided Scanning: 135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)2-sided Scanning: 270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy) |
| Communication Protocol | File: FTP (TCP/IP), up to SMB 3.11 (TCP/IP), WebDAV E-mail/1-Fax: SMTP, POP3 |
| File Format | TIFF (MMR), JPEG*10, PDF (Compact, Searchable, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word) |
| Universal Send Features | Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages |
Fax Specifications
| Optional / Standard | Optional |
| Maximum Number of Connection Lines | 2 |
| Modem Speed | Super G3: 33.6 kbps G3: 14.4 kbps |
| Compression Method | MH, MR, MMR, JBIG |
| Resolution (dpi) | 400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal) |
| Sending / Receiving Size | Sending: A3, A4, A4R, A5*11, A5R*11, A6R*11, B4, B5*12, B5R*11
Receiving: A3, A4, A4R, A5, A5R, B4, B5, B5R |
| FAX Memory | Up to 30,000 pages (2,000 jobs) |
| Speed Dials | Max. 200 |
| Group Dials / Destinations | Max. 199 dials |
| Sequential Broadcast | Max. 199 dials |
| Memory Backup | Max. 256 addresses |
| Fax Features | Sender’s Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log |
Store Specifications
| Mail Box | 100 User Inboxes 1 Memory RX Inbox 50 Confidential Fax Inboxes Maximum 10,000 Pages (2,000 jobs) Stored |
| Advanced Space | Communication Protocol: SMB or WebDAV Supported Client PC: Windows® 10/11 Concurrent Connections (Max.): SMB: 64, WebDAV: 3 |
| Advanced Space Available Disk Space | Standard: 16 GB (With option: Max. 480 GB) |
| Advanced Space Features | Authentication for Advanced Space Log-in, Sort Function, Printing a PDF File with a Password, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore |
Security Specifications
| Authentication & Access Control | User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online/uniFLOW (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Cloud Connector (PIN Login), Microsoft Entra ID (PIN Login, Card Login), Two-Factor Authentication at LUI/RUI, Access Management System (Access Control) |
| Document Security | Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*13), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark) |
| Network Security | TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), up to WPA3 (using Wi-Fi), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Space in the MFP, Scan and Send-Virus Concerns for E-mail Reception |
| Device Security | Protecting SSD Data [SSD Data Encryption (FIPS140-2/140-3*14), SSD Lock], Standard SSD Initialize, Initialize (NIST 800-88 PURGE LEVEL), Trusted Platform Module (TPM 2.0), Job Log Conceal Function, Protecting MFP Software Integrity: Verify System at Startup (NIST SP800-193: Protection), Checking MFP Software Integrity & Platform Firmware Resiliency: Automatic System Recovery (NIST SP800-193: Recovery), Runtime Intrusion Detection: Trellix Embedded Control, HCD-PP Common Criteria Certification*14 |
| Device Management & Auditing | Administrator Password, Digital Certificate And Key Management, Audit Log, SAN certificates, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting |
Environmental Specifications
| Operating Environment | Temperature: 10 to 30⁰C Humidity: 20 to 80 % RH (Relative Humidity) |
| Power Source | 220-240 V, 50/60 Hz, 6 A |
| Power Consumption | Maximum: Approx. 2,000 W Standby: Approx. 53.7 W*15 Sleep mode: Approx. 0.5 W*16 |
| Noise Levels | 65 dB, Kv 3 dB*17 |
Software & Printer Management
| Tracking & Reporting | uniFLOW Online |
| Remote Management Tools | iW Enterprise Management Console Monitoring Service Remote Distribution & Management Service |
| Scanning Software | Colour Network ScanGear 2 |
| Optimisation Tools | Canon Driver Configuration Tool |
| Platform | MEAP (Multifunctional Embedded Application Platform) |
Fiery Print Controller Specifications
| Optional/Standard | Optional |
| Name | imagePASS-T1 (Embedded) |
| Print Resolution (dpi) | 1,200 x 1,200, 600 x 600 |
| Page Description Language(s) | Adobe PS3, PCL6, Adobe PDF Print Engine (Optional) |
| Memory | 8 GB (4 GB x 2) |
| Hard Disk Drive | 500 GB SATA |
| Processor Speed | Intel Pentium Gold 5400 (3.7 GHz) |
| System | FS500 |
| Fonts | PS: 138 Fonts PCL: 113 Fonts |
| Supported Operating Systems | Windows® 10 32 bit*18 and 64 bit/Windows® 11/Windows® Server 2016/Windows® Server 2019/Windows® Server 2022/macOS 10.15, 11.0, 12, 13, 14 |
| Interface | 2 x Ethernet (1000Base-T/100Base-TX/10Base-T), USB 3.0 x 2 (Rear) |
| Network Protocols | TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SLP, SMB, LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing, Port9100, SNTP, 802.1X, DHCP, DNS, NTP) |
| Direct Print | PDF1.7, EPS, TIFF6, JDF1.4/JMF (Optional) |
| VDP | FreeForm v1, v2.1 |
| Fiery Print Controller Standard Features | Fiery Command WorkStation 7/Paper Catalog/Fiery Spot-On/Fiery Remote Scan |
| Fiery Print Controller Options | Fiery Impose/Fiery Compose/Fiery Impose and Compose/Fiery Automation package/Fiery ColorRight package/Fiery JobExpert and PDF Processing Kit |
| HW Platform | E500 |
| Base Operating System | Debian of Linux |
| Power Source | AC 100-240 V, 50/60 Hz; 1.5 A (100 V) – 1.0 A (240 V) |
| Maximum Power Consumption | 55 W |
Consumables
| Toner Cartridge/s | Toner 3001 BK/C/M/Y |
| Toner Estimated Yield | Toner (Estimated Yield @ 8.5% Coverage) Toner 3001 BK: 37,500 pages Toner 3001 C/M/Y: 27,500 pages |
Paper Supply Options
| Cassette Feeding Unit-AYl | Paper Capacity: 2 x 550 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Eco, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R Custom size: 98.0 x 148.0 mm to 304.8 x 457.2 mm Paper Weight: 52 to 300 gsm |
| High Capacity Cassette Feeding Unit-F1 | Paper Capacity: 2,450 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Eco, Colour, Heavy, Bond, Pre-punched, Letterhead Paper Size: A4 Paper Weight: 52 to 300 gsm |
| Paper Deck Unit-F2 | Paper Capacity: 2,700 sheets (80 gsm) Paper Type: Thin, Plain, Colour, Recycled, Heavy, Pre-punched Paper Size: A4, B5 Paper Weight: 52 to 256 gsm |
Output Options
| 1st Copy Tray Kit-B1 | Standard Capacity (with 80 gsm paper): A4, A5, A5R, A6R, B5: 250 sheets SRA3, A3, A4R, B4, B5R: 100 sheetsLong sheet*19: Length up to 990.0 mm: 20 sheets (151 to 163 gsm) Length up to 1,300.0 mm: 1 sheet (151 to 163 gsm) Paper Weight: 52 to 300 gsm |
| Inner 2way Tray-M1 | Tray Capacity (with 80 gsm paper): A4, A5, A5R, A6R, B5: 100 sheets SRA3, A3, A4R, B4, B5R: 50 sheetsPaper Weight: 52 to 300 gsm |
| 3rd Copy Tray Kit-A1 | Capacity (with 80 gsm paper): A4, A5R, B5: 100 sheets A3, A4R, B4, B5R: 75 sheetsPaper Weight: 52 to 300 gsm |
| Inner Finisher-N1 | Tray Capacity (with 80gsm paper):
Upper Tray: Lower Tray: Paper Weight: 52 to 300 gsm Staple Position: Corner, Double Eco Staple: Staple On Demand: Approx. 40 sheets (80 gsm) |
| Staple Finisher-AB3 | (Requires Buffer Pass Unit-R1)
Tray Capacity (with 80 gsm paper): Upper Tray: Lower Tray: Envelopes: Monarch: 30 sheets, COM10 No.10, DL, ISO-C5: 100 sheets Note: Long sheet length of up to 1300.0 mm: 20 sheet (ejected to the top of the Buffer Pass Unit-R1 and Staple Finisher-AB3) Paper Weight: Staple Position: Corner, Double Eco Staple: Staple On Demand: 65 sheets (52 to 90 gsm) |
| Paper Folding/Booklet Finisher-A2 | (Requires Buffer Pass Unit-R1) (Includes the above Staple Finisher-AB3 basic staple specifications)Saddle Stitch/V-fold paper size: A3, A4R, B4 C-fold Paper Size: A3, A4R, B4 Saddle Stitch Staple Capacity: 20 sheets x 10 sets (52 to 81.4 gsm) (including 1 cover sheet 52 to 256 gsm) V-fold Capacity: Up to 5 sheets (52 to 105 gsm) C-fold Capacity: A4R: Up to 6 sheets (52 to 90 gsm), up to 5 sheets (91 to 128 gsm) A3, B4: Up to 5 sheets (64 to 128 gsm) |
| Paper Folding Unit-L1 | (Requires Buffer Pass Unit-R1)
Paper size: A3, A4R, B4 |
| Inner 2/3 Hole Puncher-D1 | (Requires the Inner Finisher-N1)
Two or Three Holes |
| Inner 2/4 Hole Puncher-D1 | (Requires the Inner Finisher-N1)
Two or Four Holes |
| 2/3 Hole Puncher Unit-Al | (Requires either the Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2)
Two or Three Holes |
| 2/4 Hole Puncher Unit-Al | (Requires either the Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2)
Two or Four Holes |
